| Product code | 1667OF |
|---|---|
| Series | Open Frame series |
| Power | 500W |
| Input voltage | 90 - 264V |
| Dimensions | 127x74x45 (mm) |
| Net weight | 0,41 kg |
| Carton quantities | 30 pcs |
| Carton weight | 12,5 kg |
| Availability | on request |
|---|
| Model | Voltage DC (V) | Type of cooling | max. Load (A) | Output Power (W) |
| SYS1667-E012 | 12 | Natural wind blowing | 25 | 300 |
| 12 | 13 CFM | 41.66 | 500 | |
| SYS1667-E015 | 15 | Natural wind blowing | 20 | 300 |
| 15 | 13 CFM | 33.33 | 500 | |
| SYS1667-E024 | 24 | Natural wind blowing | 12.5 | 300 |
| 24 | 13 CFM | 20.83 | 500 | |
| SYS1567-E036 | 36 | Natural wind blowing | 8.33 | 300 |
| 36 | 13 CFM | 13.88 | 500 | |
| SYS1667-E048 | 48 | Natural wind blowing | 6.25 | 300 |
| 48 | 13 CFM | 10.41 | 500 | |
| SYS1667-E054 | 54 | Natural wind blowng | 5.55 | 300 |
| 54 | 13 CFM | 9.25 | 500 |
[643 kB]
SYS1667 Series Open 500W max.pdf
